HES 9500-LBSM Fire Rated Surface Mounted Electric Strike w/ Latchbolt Strike Monitor

HES 9500-LBSM Fail Safe/Fail Secure, Complete 12/24VDC Electric Strike, Surface Mounted, 3/4" Thickness, Fire Rated, Latchbolt Strike Monitor

Works with rim exit devices up to 3/4" throw Pullman latchbolt

Surface-Mounted Electric Strike for 3/4" Pullman Rim Exit Devices, fire rated; no faceplates required

The 9500 Series Electric Strike is a three hour fire rated, surface mounted electric strike designed to accommodate rim exit devices with a 3/4" throw Pullman latchbolt. All components are completely encased within its 3/4" thick stainless steel housing, so no cutting on the frame is required for installation. Simply place the electric strike on the surface of the frame, align it with the exit latchbolt and install. Adjustments have never been easier as the base is now separate from the cover.

The 9500 exceeds Grade 1 standards for strength and performance. It is field selectable for fail safe / fail secure operation, and for 12 or 24 VDC. This unique electric strike complies with NFPA 80-07 guidelines for retrofit into fire rated frames.

Standard Features
• Installs in metal or wood frames (wood screws not included)
• Separate base and decorative cover for easy adjustments
• Stainless steel construction
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Horizontal adjustability
• Non-handed
• Internally mounted solenoid
• Accommodates up to 3/4" [19mm] Pullman latch
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• UL 305 listed
• RoHS compliant
• UL 10C fire rated, 3-hour single door (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• California Fire Marshal listed
• NFPA 80-07 compliant
• WHI fire door listed

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC
• 450 mA at 12 VDC/250 mA at 24 VDC

Model: HES 9500-630-LBSM, 9500-605-LBSM, 9500-606-LBSM, 9500-612-LBSM, 9500-613-LBSM, 9500-629-LBSM
