HES 8500-LBSM Fire Rated Concealed Electric Strike for Mortise Locksets w/ Latchbolt Strike Monitor

HES 8500-LBSM Fail Safe/Fail Secure, Body Only, 12/24VDC Electric Strike, Latchbolt Strike Monitor

Works with mortise locksets without a deadbolt up to a 3/4" throw latchbolt

Universal Electric Strike; Faceplates ordered separately

The 8500 Series Electric Strike is a fire rated, compact, high performance electric strike featuring a unique concealed design for use with mortise locksets without a deadbolt. Designed for fast, convenient installation, the 8500 installs with little or no modification to the frame. Simply remove the existing strike plate, remove the dust box, and install. Its strength is derived from a unique keeper pin locking design, enabling the 8500 to exceed Grade 1 ratings. This unique electric strike complies
with NFPA 80-07 guidelines for retrofit into fire rated frames. The 8500 accommodates mortise latchbolts up to 3/4" throw.

Standard Features
• No cutting to the face of the frame
• Stainless steel construction
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Non-handed
• Metal frame
• Internally mounted solenoid
• Accommodates 3/4" [19mm] mortise latchbolts
• Strike body depth 1-5/16" [33.3mm]
• Plug-in connector
• Full pocket shims for horizontal adjustment
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal

Faceplate Options
• 851M Faceplate
For use with: Mortise locksets
Compatible locksets: Sargent 8100, 8200, 9200
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 852K Faceplate
For use with: Mortise locksets
Compatible locksets: Corbin Russwin ML 2000
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 852L Faceplate
For use with: Mortise locksets
Compatible locksets: Schlage L9000
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 852M Faceplate
For use with: Mortise locksets
Compatible locksets: Yale 8700 (manufactured after 2005) & 8800, Accurate, Falcon, Kaba Ilco/Unican
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• RoHS compliant
• UL 10C fire rated, 3-hour single door (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• NFPA 80-07 compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC/VAC
• 240 mA at 12 VDC/120 mA at 24 VDC
• PoE friendly

Model: HES 8500-630-LBSM, 8500-605-LBSM, 8500-606-LBSM, 8500-612-LBSM, 8500-613-LBSM, 8500-629-LBSM
