Adams Rite 4569 Flat Euro Lever Trim w/ Return

Adams Rite 4569 Flat Euro Lever Trim with Return

The 4560 Series Deadlatch Handles easily unlock the 4300, 4500 and 4900 Series Deadlatches. These handles fit solidly into the cylinder hole of Adams Rite deadlatches.

Function
Designed to operate 4300, 4500 and 4900 Series Deadlatches by a natural downward hand movement, these handles incorporate an activator cam plug that mounts on the handles' escutcheon and fits solidly into the cylinder hole of the latch. Not intended for use as a door pull.

4569 handles feature a return end, often required by code.

Features
Handle: Handle of cast aluminum.
4569: ADA compliant lever features a returnend, often required by code. Please verify local code requirements to ensure compliance.

Escutcheon: A 1/4" [6.4 mm] square heat-treated spindle is part of escutcheon assembly, which interlocks with the cam plug. Finished to match lever. 4568 use the same 1-3/8" x 4"[34.9mm x 101.6mm] escutcheon, designed to match the clean lines of a narrow stile door. Steel mounted base is secured by hidden screws and has two large helical compression springs (one becomes a “spare” once handing is given).

Cam Plug: Secured in latch body by cylinder set screw, the plug is also rigidly tied to handle escutcheon by hardened steel pins. Handing can be reversed by removing a spring clip, reversing the cam, and replacing the clip.

Door Thickness
01 - 1-3/4 Inch to 2 Inch
02 - 2-1/4 Inch to 2-1/2 Inch

Handing
5 - LH or LHR
6 - RH or RHR

Model: Adams Rite 4569-501-130, 4569-601-130, 4569-501-121, 4569-601-121
