Securitron WSS-WSD Wave Sense Switch, Single and Double Gang Faceplates, White Finish

Securitron WSS-WSD Wave Sense Switch with White, Single and Double Gang Faceplates

No-touch switch for hands-free activation.

A new class of motion sensing technology for hands-free, contactless switch activation. Use for request to exit (REX), activation or on/off switching to trigger a variety of access control devices in place of a push plate or push button.

Features
• Active microwave motion sensing using Doppler radar that is more reliable than infrared sensors
• Adjustable sensing zone from 4" to 24" (102mm to 610mm) helps screen out incidental traffic
• FCC certified for use in general and medical environments
• Touchless activation for hands-free operation, reduces transmission of germs
• Pulse mode to initiate action or toggle mode to provide on/off switch
• Mounting ring included or install in standard plastic or metal gang box
• Water-resistant foam gasket included
• MagnaCare® lifetime replacement, no-fault, no questions asked warranty

Specifications
Electrical
• Self-sensing 12 or 24 V DC or AC input (± 10%)

Dimensions
• Single gang faceplate 4-1/2" x 2-3/4" [114mm x 70mm]
• Double gang faceplate 4-1/2" x 4-1/2" [114mm x 114mm]

Maximum Power Consumption
• Less than 1.5 W (125 mA at 12 VDC) 1 A SPDT contact can be operated in toggle or pulse mode
• Pulse output: 0.5 seconds

Environmental
• Operating Temperature: -4˚ to 131˚ F [-20˚ to 55˚ C]
• Indoor use

Certifications
• Electromagnetic compatibility to 2004/108/EC
• FCC: G9B-MS08 and IC: 4680A-MS08

Model: Securitron WSS-WSD
