Securitron M82B-SS Magnalock w/ 1800 lbs Holding Force, Direct Mount, BondSTAT Monitor, Split Strike

Securitron M82B-SS Maglock, 1800 lbs Holding Force, Direct Mount, 12/24VDC, BondSTAT Monitor, Split Strike

Industrial strength hold for challenging indoor/outdoor environments.
The M82 electromagnetic lock offers unsurpassed magnetic holding strength, durability and ease of maintenance for interior, perimeter and exterior access control applications in high-risk environments. With unsurpassed durability, the M82 will last long after most buildings wear out. Flexible mounting options are available for higher security locations and other environments where extreme forces may be encountered.

Features
• Efficient, low power usage
• Automatic dual-voltage—no field adjustment required
• Fully sealed for weather resistant operations
• Rust resistant—all ferrous metal surfaces plated for durability
• Instant release circuit—no residual magnetism
• Noise suppression with built-in MOV
• 10 ft [3.05m] of jacketed, stranded conductor cable
• Ultra-secure collapsing blind nuts mount to door frame for strength and reliability
• MagnaCare® lifetime replacement, no-fault, no questions asked warranty

Split Strike Plate (SS)
A Split Strike Plate may be used for a double door with no mullion to provide traffic control using a single Magnalock.

BondSTAT (B)
BondSTAT is the next generation of patented electromagnetic lock monitoring. BondSTAT delivers unparalleled peace of mind by detecting an armature plate and notifying access control and/or alarm systems that a door is properly secured. BondSTAT’s sensitive magnetic field monitors the entire surface of the armature plate, providing maximum assurance that the lock is engaged. Movement in the armature’s position beyond the set tolerance alerts the access control system that the Magnalock may not be generating its full holding force.

Specifications
Electrical
• 350 mA at 12 VDC
• 200 mA at 24 VDC

Holding Force
• 1,800 lbs [816kg]

Operating Temperature
• -40˚ to 140˚F [-40˚ to 60˚C]
• Indoor or Outdoor use

Certifications
• UL 10C Listed
• CAN4-S104, CAN/ULC-S533 Listed
• ANSI/UL 294 Listed
• ANSI/BHMA A156.23, Grade 1;
E08501-1500 Compliant
• CSFM—California State Fire Marshal Approved
• CE:EN 50081-1(92), EN 61000-6-2(99) Approved

Model: Securitron M82B-SS
