Securitron M680EBDX EcoMag Magnalock w/ 1200 lbs Holding Force, BondSTAT Monitor and Door Position Switch, Request to Exit

Securitron M680EBDX M680E Maglock, 1200 lbs Holding Force, 12/24 VDC Bondstat Monitor, DPS, Request To Exit

The same unsurpassed intelligence, style and convenience as the previous M680 series, but with 80% reduction in energy consumption.

The M680E is intelligent, with built-in door prop sensing allowing the magnet to deenergize the coil when the door is held open for extended periods. The M680EBD offers built-in smart voltage sensing, integrated patented BondSTAT, tamper sensor as well as door position status monitoring. The aesthetics and design finishes of the EcoMag are refined enough for the most discriminating designer openings. It also offers the fastest, easiest, most secure installation of any bracket mount maglock with an updated strike plate mounting template.

The Integrated request to exit (REX) provides optimum coverage for detecting an approaching person so the door unlocks for egress.

Features
• Strike plate mounting template provides the easiest install for out-swing doors
• LED Indicator shows the lock is secure, open, or has an incomplete bond
• Wire chamber anti-tamper switch
• Tamper Switch sends an alarm output if the cover is removed and is selectable to NO or NC
• Available integrated BondSTAT and Door Position Switch
• Autosensing dual voltage with microprocessor technology
• Adjustable automatic relock timer (0 to 30 seconds)
• Energy efficient, low power usage
• Size optimized for use with door closers
• MagnaCare® lifetime replacement, no-fault, no questions asked warranty

BondSTAT (B)
BondSTAT is the next generation of patented electromagnetic lock monitoring. BondSTAT delivers unparalleled peace of mind by detecting an armature plate and notifying access control and/or alarm systems that a door is properly secured. BondSTAT’s sensitive magnetic field monitors the entire surface of the armature plate, providing maximum assurance that the lock is engaged. Movement in the armature’s position beyond the set tolerance alerts the access control system that the Magnalock may not be generating its full holding force.

Door Position Switch (DPS)
The Door Position Switch (DPS) provides a signal to an access control system indicating whether the door is open or closed. When used in conjunction with BondSTAT or SenSTAT, it provides layered status indication for precise information about the door state. The DPS may be ordered included with many Securitron Magnalocks — or as an upgrade kit.

Request to Exit (X)
Some Securitron Magnalock models offer an integrated motion detector that automatically signals the lock to disengage when it detects approaching traffic, also known as request to exit (REX).

Specifications
Electrical Consumption
• Maglock Average Power Draw (±10%)
 113 mA at 12 VDC
  52 mA at 24 VDC
• Maglock Maximum Power Draw (±10%)
 515 mA at 12 VDC
 290 mA at 24 VDC
• REX Power (±10%)
+25 mA at 12 VDC
+10 mA at 24 VDC

Holding Force
• 1200 lbs [544kg]

Operating Temperature
• 32˚ to 110˚F [0˚ to 43˚C]
• Indoor use only

Certifications
• UL 10C Fire Rated, 1 Hour
• CAN/ULC-S104 Fire Door Conformant
• UL 1034 Burglary-Resistant Listed
• UL 294
• ANSI/BHMA A156.23, Grade 2; E18501 Compliant
• California State Fire Marshal Listed

Model: Securitron M680EBDX 628, M680EBDX 613E, M680EBDX 612, M680EBDX 630
