Securitron M62FG Magnalock w/ 1200 lbs Holding Force, Face Drilled, Gate Conduit, Standard Strike

Securitron M62FG Magnalock, 1200 lbs Holding Force, 12/24VDC, Face Drilled, Conduit Fitting, Standard Strike

The ultimate in Magnalock versatility for indoor/outdoor higher security. The M62 is a strong, easy-to-maintain solution for interior, perimeter and exterior access control. With unsurpassed durability, the M62 will last long after most buildings wear out. Flexible mounting options support applications for hollow metal, concrete filled metal, wood, or glass with aluminum frames, and all glass doors. Options include single and double door configurations, or specialty applications such as gates and fences, and hazardous locations.

Features
• Fire rated—3 hours
• PoE friendly
• Sustainability documentation
• Efficient, low power usage
• Automatic dual-voltage—no field adjustment required
• Fully sealed for weather resistant operations
• Size optimized for use with door closers
• Rust resistant—all ferrous metal surfaces plated for durability
• Instant release circuit—no residual magnetism
• Noise suppression with built-in MOV
• 10 ft [3.05m] of jacketed, stranded conductor cable
• Ultra-secure collapsing blind nuts mount to door frame for strength and reliability
• MagnaCare® lifetime replacement, no-fault, no questions asked warranty

Mounting Type
Face Mount (F)
Face Mount Magnalock options provide the holes for the mounting bolts through the face of the magnet in a front-to back orientation rather than through the magnet bottom-to-top.

Conduit Fitting (G)
The conduit fitting option is offered on some Magnalocks that can be used for gate-mounting applications and features a 3/4" outer diameter and 1/2" inner diameter.

Monitoring Options
BondSTAT (B)
BondSTAT is the next generation of patented electromagnetic lock monitoring. BondSTAT delivers unparalleled peace of mind by detecting an armature plate and notifying access control and/or alarm systems that a door is properly secured. BondSTAT’s sensitive magnetic field monitors the entire surface of the armature plate, providing maximum assurance that the lock is engaged. Movement in the armature’s position beyond the set tolerance alerts the access control system that the Magnalock may not be generating its full holding force.

Door Position Switch (DPS)
The Door Position Switch (DPS) provides a signal to an access control system indicating whether the door is open or closed. When used in conjunction with BondSTAT or SenSTAT, it provides layered status indication for precise information about the door state. The DPS may be ordered included with many Securitron Magnalocks — or as an upgrade kit.

Specifications
Electrical
• 250 mA at 12 VDC
• 150 mA at 24 VDC

Holding Force
• 1,200 lbs [544kg]

Operating Temperature
• -40˚ to 140˚F [-40˚ to 60˚C]
• Indoor or Outdoor use

Certifications
• UL 10C Listed
• CAN4-S104, CAN/ULC-S533 Listed
• ANSI/UL 294 Listed
• CSA-C22.2 No.205 Listed
• ANSI/BHMA A156.23, Grade 2; E08501-1000 Compliant
• CSFM—California State Fire Marshal Approved
• CE:EN 50081-1(92), EN 61000-6-2(99) Approved
• Environmental Product Declaration
• Health Product Declaration
• UL 294 Class I, Division 2, Groups A, B, C and D Listed (-EX configuration only)

Model: Securitron M62FG, M62FGB, M62FGD, M62FGBD
