Securitron DM62 Magnalock for Double Door w/ 1200 lbs Holding Force, Standard Strike

Securitron DM62 Maglock, Double Door Application, 1200 lbs Holding Force, Bracket Mount, 12/24VDC

The versatile DM62 electromagnetic lock offers strength and ease of maintenance for interior, perimeter and exterior access control—in a compact double magnet.
This all-in-one unit is designed for double doors with no mullion. With unsurpassed durability, the DM62 will last long after most buildings wear out.

Features
• Ultra-secure collapsing blind nuts mount to door frame for strength and reliability
• Fully sealed for weather resistant operations
• 3' [1 m] of jacketed, stranded conductor cable for each lock
• Automatic dual-voltage—no field adjustment required
• Instant release circuit—no residual magnetism
• Noise suppression with built-in MOV
• Efficient, low power usage
• Rust resistant — all ferrous metal surfaces plated for durability
• MagnaCare® lifetime replacement, no-fault, no questions asked warranty

BondSTAT (B)
BondSTAT is the next generation of patented electromagnetic lock monitoring. BondSTAT delivers unparalleled peace of mind by detecting an armature plate and notifying access control and/or alarm systems that a door is properly secured. BondSTAT’s sensitive magnetic field monitors the entire surface of the armature plate, providing maximum assurance that the lock is engaged. Movement in the armature’s position beyond the set tolerance alerts the access control system that the Magnalock may not be generating its full holding force.

Door Position Switch (DPS)
The Door Position Switch (DPS) provides a signal to an access control system indicating whether the door is open or closed. When used in conjunction with BondSTAT or SenSTAT, it provides layered status indication for precise information about the door state. The DPS may be ordered included with many Securitron Magnalocks — or as an upgrade kit.

Specifications
Electrical (Per Lock)
• 250 mA at 12 VDC
• 150 mA at 24 VDC

Holding Force
• 1,200 lbs [544kg]

Operating Temperature
• -40˚ to 140˚F [-40˚ to 60˚C]
• Indoor or Outdoor use

Certifications
• UL 10C Listed
• CAN4-S104, CAN/ ULC-S533 Listed
• ANSI/BHMA A156.23, Grade 2; E08511-1000 Compliant
• CSFM- California State Fire Marshal Approved

Model: Securitron DM62B, DM62BD, DM62
