Schlage HL6-5 Hospital Push Pull Latch

Hospital Push/Pull Tubular Latch, Passage Function, 5" Backset, Spring Latch (Unguarded).

Functions: HL6 - Passage lock
• Latchbolt retracted by paddle from either side
• Inside paddle alway

Mounting positions:
· Handles down
· Handles up
· One handle up, one handle down (push or pull)
· Handles point away from latch
· Handles point toward latch

Backset: Standard: 5

Strike Standard: 2 3⁄4" Optional ASA: 4 7⁄8" (A)

Handing: Non-handed

Door thickness: 1 3⁄4" only

Latchbolt: 1⁄2" throw stainless steel

Certifications: UL Listed for 3-hour fire door, 4' x 8'

Finish: 626 Satin chrome (US26D), 613 Oil rubbed bronze (US10B)

Features and benefits

· Quiet functionality
· Passage function
· Six mounting positions
· 10 finishes, including antimicrobial options
· Six available options, including engraving on handles
· Four backset sizes
· Two strike options
· Non-handed
· UL listed for all single labeled metal or wood doors
