Sargent V03-10XG04 VSLL 26D Storeroom Cylindrical Lock w/ Inside Status Indicator

Sargent V03-10XG04 VSLL 26D Grade 1 Storeroom or Closet Cylindrical Lock, L Lever, VSL Rose, Inside Indicator with Green/Red Icons, Satin Chrome Finish, Non-Handed

Function Description: Storeroom or Closet - ANSI F86
• Deadlocking latch
• Latch by lever inside or key outside
• Outside lever locked at all times

V03 (Single Indicator): Color Green/Red
Outside: Standard Trim
Inside: Indicator Trim

Features
• Patented design
• Inside, outside or both sides of the door
• Highly visible from all angles
• Non-handed
• Multiple door thickness options
• Available with a variety of functions

Door Prep: ANSI/SDI A250.14

Door Thickness: 1-3/4" (44mm) standard - accomodates 1-11/16" - 1-15/16" (43mm - 49mm) doors

Minimum Stile: 4-1/2" (114mm)

Handing: Non-handed

Cylinder: Brass, 6-pin LA keyway, 1-bitted standard; 60 - Lock to accept LFIC (removable core) and provided with disposable plastic core, 70 - Lock to accept SFIC (6 or 7-pin, removable core) and provided with disposable plastic core, LC - Lock supplied less Cylinder

Keys: Two nickel silver change keys per lock standard

Masterkeying: Can be master keyed or grand master keyed

Backset: 2-3/4" (70mm) backset w/ 1-1/8" (29mm) front (standard)

Latchbolt: Stainless steel, 1/2" (13mm) throw

Front: Wrought brass and stainless steel. 2-1/4" x 1-1-8" (57mm x 29mm) Fixed Bevel

Strike: Wrought brass, bronze and stainless steel 808 curved lip ANSI 4-7/8" strike (standard)

Outside Locked Lever: Rigid outside locked levers provided standard

Warranty: Ten-year limited

Model: Sargent V03-10XG04 VSLL 26D, 60-V03-10XG04 VSLL 26D, 70-V03-10XG04 VSLL 26D, LC-V03-10XG04 VSLL 26D
