Sargent 716 ETJ Classroom Security Exit Trim, For 8816, 12-8816, 8916, 12-8916 Devices

Sargent 716 ETJ Grade 1 Exit Device Trim, Classroom Security Function, Key Outside Retracts Latch, Key Inside
Unlocks/Locks Outside Trim, For 8700, 8900 Series Devices, Rim Cylinder Inside, 1-1/2 In. Mortise Cylinder Outside, J Lever

The 700 Series trims are through-bolted to the chassis for greater security and durability.

Function: Classroom Security - ANSI No.10
Key inside unlocks/Locks outside trim

Cylinder Type: #44 Mortise Cylinder Inside, #34 Rim Cylinder Outside - LA Keyway

For Use With: 8816, 12-8816, 8916, 12-8916 Devices

Lever Style: J Lever

Trim Style: ET

Trim Plate Width: 1-13/16 Inch

Trim Plate Height: 8-1/16 Inch

Product Projection: 3-9/16 Inch

Trim Plate Thickness: 13/16 Inch

Finishes: 26D - Satin Chrome, 10 - Satin Bronze Clear Coated, 4 - Satin Brass, 3 -Bright Brass, 10B - Dark Oxidized Satin Bronze Oil Rubbed, 26 - Bright Chrome

Model: Sargent 716 ETJ RHRB 26D, 716 ETJ LHRB 26D, 716 ETJ RHRB 3, 716 ETJ LHRB 3, 716 ETJ RHRB 10, 716 ETJ LHRB 10, 716 ETJ RHRB 10B, 716 ETJ LHRB 10B, 716 ETJ RHRB 26, 716 ETJ LHRB 26
