Sargent 706 ETJ Storeroom Exit Trim, For Surface Vertical Rod and Mortise Devices

Sargent 706 ETJ Grade 1 Exit Device Trim, Storeroom Function, Key Unlocks Trim, Trim Retracts Latch/Trim Relock
when Key is Removed, For Surface Vertical Rod and Mortise 8700, 8900, 9700 Series Devices, 1-1/8 In. Mortise Cylinder,
J Lever, Satin Chrome

The 700 Series trims are through-bolted to the chassis for greater security and durability.

Function: Storeroom - ANSI No.09
Key unlocks Trim, Trim retracts latch/Trim relocks when key is removed

Cylinder Type: Sargent #41 Mortise Cylinder - LA Keyway

For Use With: 8700, 8900, 9700 Series Surface Vertical Rod and Mortise Devices - 8706, 12-8706, 8906, 9706, 12-9706

Lever Style: J Lever

Trim Style: ET

Trim Plate Width: 1-13/16 Inch

Trim Plate Height: 8-1/16 Inch

Product Projection: 3-9/16 Inch

Trim Plate Thickness: 13/16 Inch

Finishes: 26D - Satin Chrome, 10 - Satin Bronze Clear Coated, 4 - Satin Brass, 3 -Bright Brass, 10B - Dark Oxidized Satin Bronze Oil Rubbed, 26 - Bright Chrome

Model: Sargent 706 ETJ RHRB 26D, 706 ETJ LHRB 26D, 706 ETJ RHRB 3, 706 ETJ LHRB 3, 706 ETJ RHRB 10, 706 ETJ LHRB 10, 706 ETJ RHRB 10B, 706 ETJ LHRB 10B, 706 ETJ RHRB 26, 706 ETJ LHRB 26
