Rixson H117-3/4 Center Hung Pivot for 2" Minimum Thick Doors, Includes H340 Top Pivot

Rixson H117-3/4 Center Hung Pivot for 2" Doors or Greater, Includes H340 Top Pivot, 1000lbs Max Door Weight

The H117-3/4 is a center-hung, heavyweight pivot set designed for interior or exterior doors weighing up to 1000lbs., with a 2" minimum thickness.

Features
• Exterior or interior doors
• Weight to 1,000 lbs.
• Door Sizes up to 4'0"x 8'6"* (1219 x 2591mm)
• Non-handed
• H340 top pivot included
• Bottom pivot is mortised into floor
• End load arm for minimum 2" (51mm) thick doors
• Pivot point centered in thickness of door
• Additional surface applied thrust bearing
• Door must have radius on pivot edge
• Pivot point remains constant at 2-3/4" (70mm) from the edge of the door
• Pivot set features sealed bearings for protection against weather and debris
• Not allowed for use on labeled doors and frames
• Furnished with wood and machine screws
• Available in plated finishes

Model: Rixson H117-3/4 626, H117-3/4 605, H117-3/4 613, H117-3/4 606, H117-3/4 612, H117-3/4 625
