Rixson 547 3/4" Offset Hung Pivot w/ 2 each of M190 Intermediate Pivots

Rixson 547 3/4" Offset Hung Pivot, Includes 2 Each M190 Intermediate  Pivots and Bottom Pivot

The 547 is an offset-hung pivot set designed for arch top or overhead concealed closers on interior or exterior doors weighing up to 500lbs

Features
• Exterior or interior doors
• For arch top doors or overhead concealed closers
• Weight to 500 lbs.
• Door width up to 3'6" (1067mm)
• Handed
• Set consists of two each M190 intermediate pivots and bottom pivot
• 3/4" (19mm) offset (measured from centerline of pivot to face of door)
• Door edges must be beveled 1/8" in 2"
• Bottom pivot mounts directly to floor
• Doors will swing 180°, trim permitting
• Non-ferrous base material
• Doors 60" (1524) to 90" (2286mm) in height have two intermediate pivots. Each additional 30" (762mm) of door height warrants another intermediate pivot
• Furnished with wood and machine screws

Model: Rixson 547 LH 626, 547 RH 626, 547 LH 605, 547 RH 605, 547 LH 606, 547 RH 606, 547 LH 613, 547 RH 613, 547 LH 625, 547 RH 625
