RCI F1114 Fire Rated Electric Strike w/ 4-7/8" Faceplate, Fail Secure, Satin Stainless Steel Finish

RCI F1114 Fire Rated Electric Strike, 4-7/8" Faceplate, For 3/4" Projection Latches, Fail Secure, Satin Stainless Steel

The F1 series of centerline strikes are made of stainless steel and feature a faceplate with square corners. The RCI F1114 is ideal for hollow metal frames and the RCI F1119 is best utilized with aluminum and wood frames. These centerline strikes are saddle-mounted for enhanced strength and allow up to a 1/4'” horizontal adjustment to relieve side-load pressure and ensure proper latch alignment. The RCI F1 Series electric strikes are built with a unique anti-vibration feature built-in and a "Pry-Guard" for tamper-resistance.

Faceplate: 1-1/4”W x 4-7/8”H (32mm x 124mm)
Insert Depth: 1-3/4” (45mm)

Features
• Stainless steel faceplate with square corners
• Accommodates 1/2” (12.7mm), 5/8” (16mm) or 3/4” (19mm) latch projection
• Up to 1/4” (6.4mm) horizontal adjustment, relieves side-load pressure, ensuring proper latch alignment
• Saddle-mount housing design for enhanced strength and durability
• Tamper-resistant pry-guard concealed inside the frame
• Energy efficient coil design
• Mounting tabs, shims and fasteners included
• Non-handed
• Brushed Stainless Steel (32D) finish
• UL 1034 burglary-resistant Listed
• UL 10C, 1-1/2 hour fire-rating Listed
• CAN/ULC S104, 1-1/2 hour fire-rating Listed
• Certified to ANSI/BHMA standard A156.31, Grade 1, endurance 500,000 cycles

Model: RCI F1114-05 32D, F1114-08 32D
