RCI 0162 32D 3/4" Surface Mounted Electric Strike for Pullman Latch Rim Exit Device, Satin Stainless Steel Finish

RCI 0162 32D Electric Strike, 3/4" Surface for Rim Devices, 12/24VDC, 12 to 24VAC, Fail Secure, Satin Stainless Steel

The 0162 electric strike accommodates 1/2" to 3/4" latch projection and is designed for use with Pullman latch rim exit devices. As a completely surface mounted strike the RCI 0162 requires no cutting of the door frame. The rugged stainless-steel strike accommodates hollow metal, aluminum and wood door frames. Its heavy-duty housing is reinforced to eliminate twisting in the case of imperfect frames. The one-piece conventional keeper promotes even load distribution for increased security in the event of an attempted forced entry.

Dimensions: 1-3/4" W x 9" H x 3/4" D (45mm x 229mm x 20mm)

Features
• Completely surface-mounted – no frame cutting required
• Accommodates 1/2” to 3/4” (13mm–19mm) latch projection
• Stainless steel ensures superior strength and creates a sleek aesthetic design
• Horizontal adjustment ensure proper latch positioning to compensate for door misalignment – up to 1/4” (6.4mm)
• Conventional keeper design (one moving part)- promotes even load distribution
• Plug-in wire connectors
• Lockdown holes for secure mount
• HEX socket head cap screws for added support
• Installation tool included (HEX key)
• Non-handed (featuring horizontal solenoid design)
• 1/16” (1.5mm) mounting spacers for additional latch engagement included
• Brushed Stainless Steel (32D) finish
• Factory tested to over 4-million cycles of operation
• Certified to ANSI/BHMA standard A156.31, Grade 1, endurance 500,000 cycles (R01629 & RF01629)
• UL 294 Listed for Access Control Unit Accessory (6th Edition)
• UL 1034 burglary-resistant Listed
• UL 10C, 3-hour fire-rating Listed2
• CAN/ULC S104, 3-hour fire-rating Listed2
• California State Fire Marshal Listed (CSFM: 3776-2275:0501)2
• Patent #: US 7,722,097
• Patent #: Canadian 2,597,916

Model: RCI 0162 32D
