PHI Precision FL2308 Fire Rated Mortise Exit Device, Key Locks/Unlocks Lever/Knob Prep (No Trim)

PHI Precision FL2308 Grade 1 Fire Rated Mortise Exit Device, Wide Stile Pushpad, Key Locks/Unlocks Lever/Knob Prep (No Trim), Less Dogging, Field Reversible

Trim Function: Key Locks/Unlocks Lever/Knob Prep (No Trim)

Door Sizes
Width:
36" - 2'-7" to 3' Door Width
48" - 3'-1" to 4' Door Width

Dogging: Less Dogging

Handing: Handed

Device: Covers ANSI A115.2 (Type 161), A115.18 cylinder lock and A115.1 (Type 86) Mortise Lock preparation

Base Material: The Cover, Touchbar, Device Channel, Lock/Hinge Side Filler and End Cap are furnished of heavy wrought Brass, Bronze or Stainless Steel. 628 Devices are furnished with Aluminum, Brass, Bronze and Stainless Steel components.

Chassis: Investment Cast Steel, Zinc Dichromated.

Latchbolt: Stainless Steel, Deadlocking, 3/4" throw, anti-friction

Strike: No. S982, handed curved lip strike furnished standard

Touchbar Height: 39-15/16" from floor standard. May be varied as situation dictates.

UL Listed: Panic and Fire Exit Hardware. Conforms to UL10C and UBC 7-2.

ANSI/BHMA: Devices are BHMA certified for ANSI 156.3, Grade 1.

Cylinders: Mortise Type, not furnished standard.

Retrofit Applications: The 2300 and FL2300 Series Devices are designed to retrofit into other manufacturers’ mounting hole locations. 1700 Series Pull Trim and 4900 Series Lever Trim may also be factory set for these applications by specifying prefix “R” (e.g. 2308 R4908A). Consult factory for details.

Exit Series: Handed Fits doors machined per ANSI A115.1 (Type 86) Mortise Lock preparation.

Backset: 2-3/4".

Case: Wrought Steel, Zinc Dichromate finish.

Lock Front Plate: 8" x 1-1/4" Bronze, Brass or Stainless Steel, pivots for beveled or square edged doors

Guardbolt: Stainless Steel, sliding type

Finishes: 605, 606, 612, 613, 622, 625, 626W, 628, 630, 690

Model: PHI Precision FL2308 628, FL2308 605, FL2308 606, FL2308 612, FL2308 613, FL2308 625, FL2308 630
