Ives 7226 BTM 3/4" Offset Bottom Pivot, 600lb w/ Bottom Base Mount

Ives 7226 BTM 3/4" Offset, Bottom Pivot, 600lb, Base Plate Mount, Non-Fire Rated

Ives offers 3/4" offset pivots designed for heavy-duty applications, supporting doors up to 600 pounds. These pivots ensure robust support, precise alignment, and ease of installation

3/4" Offset pivot, 600lb with bottom base mount
• Maximum door load 600 pounds
• Recommended for use with 1-3/4" minimum door thickness, with 1/8" bevel in 2"
• Vertical adjustment range 3/16", with positive locking
• Non-handed
• 7226 Btm (7226 Btm), base plate mount

Specifications
Material substrate: Made from cast brass

Certifications
• Meets ANSI/BHMA A156.4 C07162
• UL 10C Listed (20 min)

Model: Ives 7226 BTM US26D, 7226 BTM SP28, 7226 BTM SP313
