HES Folger Adam 700 Series Electric Strike

Folger Adam 700 Works with cylindrical and mortise locksets without a deadbolt

The Folger Adam 700 series is a 3-hour fire rated, industrial grade electric strike designed for extreme heavy duty applications. The all stainless steel construction of this device makes it ideal for high abuse applications. The Folger Adam 700 Series is designed to accommodate 1/2" throw latchbolts, and the Folger Adam 712-75 is designed to accommodate 3/4" latchbolts.
*NOTE: These products will require relocation of the center line when used with mortise locks.

Standard Features
• Tamper resistant, heavy duty construction
• Constructed entirely of stainless steel for strength and corrosion resistance
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Horizontally adjustable keeper allows for door and frame misalignment
• 1/2" [12.7mm] keeper depth (712 and 732)
• 3/4" [19mm] keeper depth (712-75 and 732-75)
• Non-handed
• Fail secure (standard)
• Plug-in connector
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Application
712
For use with 1/2" [12.7mm] to 5/8" [15.9mm] throw latchbolts in hollow metal frame applications.
1/2" [12.7mm] Keeper standard

712-75
For use with 1/2" [12.7mm]*, 5/8" [15.9mm]* or 3/4" [19mm] throw latchbolts in hollow-metal frame applications.
3/4" [19mm] Keeper standard

732
For use with 1/2" [12.7mm]* to 5/8" [15.9mm]* throw latchbolts in wood frame applications. Features an offset solenoid.
1/2" [12.7mm] Keeper standard

732-75
For use with 1/2" [12.7mm]*, 5/8" [15.9mm]* or 3/4" [19mm] throw latchbolts in wood frame applications. Features an offset solenoid.
3/4" [19mm] Keeper standard

Optional Features
• Fail Safe
• LBMLCM Latchbolt & Locking Cam Monitor

Certifications
• UL 10C fire rated, 3-hour single door (fail secure only)
• UL 10C fire rated, 3-hour double door (fail secure only)
• CAN4-S104 (ULC-S104) fire door conformant
• UL 1034, burglary-resistant listed
• UL 294 listed
• ANSI/BHMA A156.31, Grade 1
• NFPA-252 fire door conformant
• ASTM-E152 fire door conformant
• RoHS compliant

Electrical (DC Continuous Duty)
• 290 mA at 12 VDC/150 mA at 24 VDC
• PoE friendly

Model: HES 712 12D 630, 712 24 630, 712 12D 605, 712 24D 605, 712 12D 606, 712 24D 606, 712 12D 612, 712 24D 612, 712 12D 613, 712 24D 613, 712 12D 629, 712 24D 629
