HES 9800 Surface Mounted Electric Strike for Adams Rite Device

HES 9800 Fail Safe/Fail Secure, Complete 12/24VDC Electric Strike, Surface Mounted, Grade 1, 1/2 In. Thick Strike Body, Non-Handed

Works with Adams Rite® Starwheel® and Interlocking rim exit devices

Surface Mounted Electric Strike for Adams Rite® Starwheel and Interlocking Rim Exit Devices; no faceplates required

The 9800 Series Electric Strike exceeds Grade 1 standards for strength and performance. All functions are performed within the 1/2" thick strike body, which is protected by a sleek stainless steel cover to conceal the mounting screws and provide the most aesthetic appearance. All while being field selectable for fail secure or fail safe operation, and dual voltage, 12 or 24 VDC.

1/16" and 1/8" spacer plates are provided to accommodate varying door gaps. Simply place the electric strike on the surface of the frame, align it with the Starwheel.

Standard Features
• Compatible with Adams Rite 8700 and 8800 Series Rim Exit Devices
• Installs on aluminum, hollow metal and wood frames (wood screws not provided)
• One 1/16" [1.6mm] spacer plate included
• One 1/8" [3.2mm] spacer plate included
• Decorative cover for sleek look
• Stainless steel construction
• Tamper-resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Horizontal adjustment
• Non-handed
• Internally mounted solenoid
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Aluminum
• Hollow Metal
• Wood

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• UL 305 listed
• RoHS compliant

Holding Force
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC
• 450 mA at 12 VDC/250 mA at 24 VDC

Model: HES 9800-630, 9800-605, 9800-606, 9800-612, 9800-613, 9800-629
