HES 9700-LBSM Fire Rated Surface Mounted Electric Strike for Squarebolt Rim Device w/ Latchbolt Strike Monitor

HES 9700-LBSM Fail Safe/Fail Secure, Complete 12/24VDC Electric Strike, Surface Mounted, 3/4" Thickness, Fire Rated, Latchbolt Strike Monitor

Works with Corbin Russwin SecureBolt® and Yale SquareBolt® exit devices

Surface Mounted Electric Strike for Corbin Russwin SecureBolt® and Yale SquareBolt® Rim Exit Devices; no faceplates required

The 9700 Series Electric Strike is a heavy duty, surface mounted electric strike designed to accommodate Corbin Russwin
SecureBolt® and Yale SquareBolt® exit devices. All components are completely encased within its 3/4" thick stainless steel housing, so no cutting on the frame is required for installation. It is field selectable for fail secure or fail safe operation, and for 12 or 24 VDC.

The 9700 is designed with the strength and durability required to exceed the severe forces of ANSI Windstorm testing. This unique electric strike also complies with NFPA 80-07 guidelines for retrofit into fire rated frames.

Standard Features
• Installs in metal or wood (wood screws not included)
• Separate base and decorative
cover for easy adjustments
• Stainless steel construction
• Tamper resistant
• Static strength to 2,000 lbs
• Dynamic strength to 120 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Horizontal adjustment
• Non-handed
• Internally mounted solenoid
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• UL 305 listed
• RoHS compliant
• UL 10C fire rated, 3-hour single door (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• California Fire Marshal listed
• NFPA 80-07 compliant
• ANSI/SDI A250.13 windstorm resistant
• Florida Building Code approved TAS 201, 202, 203
• ANSI-ASTM E330

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC
• 450 mA at 12 VDC/250 mA at 24 VDC

Model: HES 9700-630-LBSM, 9700-605-LBSM, 9700-606-LBSM, 9700-612-LBSM, 9700-613-LBSM, 9700-629-LBSM
