HES 9400-LBM Slim-line, Surface Mounted Electric Strike w/ Latchbolt Monitor

HES 9400-LBM Fail Safe/Fail Secure, Complete 12/24VDC Electric Strike, Surface Mounted, 1/2" Thickness, Latchbolt Monitor

Works with rim exit devices up to 1/2" throw latchbolt

Surface-Mounted Electric Strike for 1/2" Pullman
Rim Exit Devices; no faceplates required

The 9400 Series Electric Strike is a slimline, surface mounted electric strike designed to accommodate rim exit devices with a 1/2" throw Pullman latchbolt. All components are completely encased within its 1/2" thick stainless steel housing, so no cutting on the frame is required for installation. Simply place the electric strike on the surface of the frame, align it with the exit latchbolt, and install.

An 1/8" spacer plate is provided to accommodate varying door gaps. The 9400 exceeds Grade 1 standards for strength and performance. It is field selectable for fail safe/fail secure operation, and for 12 or 24 VDC. The 9400 features a smooth cover to conceal the mounting screws and provide a sleek surface for superior looks.

Standard Features
• Installs in metal and wood frames
• Wood screws not provided
• One 1/8" [3.2mm] spacer plate included
• Decorative cover for sleek look
• Stainless steel construction
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Horizontal adjustability
• Non-handed
• Internally mounted solenoid
• Accommodates up to 1/2" [12.7mm] Pullman latch
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• UL 305 listed
• RoHS compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC
• 450 mA at 12 VDC/250 mA at 24 VDC

Model: HES 9400-630-LBM, 9400-605-LBM, 9400-606-LBM, 9400-612-LBM, 9400-613-LBM, 9400-629-LBM
