HES 8300-LBM Fire Rated Concealed Electric Strike for Cylindrical Locksets w/ Latchbolt Monitor

HES 8300-LBM Fail Safe/Fail Secure, Body Only, 12/24VDC Electric Strike, Latchbolt Monitor

Works with cylindrical locksets and accommodates latchbolts up to 5/8" throw

Universal Electric Strike; Faceplates ordered separately

The 8300 Series Electric Strike is a fire rated, compact, high performance electric strike featuring a unique concealed design for use with cylindrical locksets. No cutting on the frame is required. Simply remove the existing ANSI strike plate, adjust the
vertical alignment feature to the latchbolt centerline and install. Its strength is derived from a unique keeper pin locking design, enabling the 8300 to exceed the ratings of the frame, door and locking hardware. This unique electric strike is easy to install and complies with NFPA 80-07 guidelines for retrofit into fire rated frames. The 8300 accommodates latchbolts up to 5/8" throw.

Standard Features
• Complies with the guidelines for retrofit into fire rated frames
• No cutting on frame required for 4-7/8" ANSI prep
• Vertical adjustability to accommodate door sag and misalignment
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Non-handed
• Accommodates 1/2" – 5/8" [12.7mm – 15.9mm] cylindrical latchbolt (5/8" [15.9mm] with 1/8" [3.175] door gap)
• Strike body depth 1-1/16" [27.3mm]
• Plug-in connector
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood
• Aluminum

Faceplate Options
• 801 Faceplate
For use with: Cylindrical locksets in ANSI metal jambs, with latchbolts up to 5/8" [15.9mm] throw.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 801A Faceplate
For use with: Cylindrical locksets with latchbolts up to 5/8" [15.9mm] throw. Includes universal mounting tabs. Aluminum frames.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 801E Faceplate
For use with: Extended lip for ‘knock-down’ style frame installations. For use with cylindrical latchbolts up to 5/8" [15.9mm] throw.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 802 Faceplate
For use with: Cylindrical locksets with latchbolts up to 5/8" [15.9mm] throw. Includes universal mounting tabs. Aluminum frames.
ANSI/BHMA Numbers: E05031, #E09321, E09322, E09323
• 803 Faceplate
For use with: Cylindrical locksets with latchbolts up to 5/8" [15.9mm] throw. Includes universal mounting tabs. Aluminum frames.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 805 Faceplate
For use with: Cylindrical locksets. Latchbolts up to 5/8" [15.9mm] throw. Four point mounting for wood installations.
ANSI/BHMA Numbers: #E05031, #E09321, #E09322, #E09323

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• RoHS compliant
• UL 10C fire rated, 3-hour single door (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• NFPA 80-07 compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC/VAC
• 240 mA at 12 VDC/120 mA at 24 VDC
• PoE friendly

Model: HES 8300-LBM
