HES 8000 Concealed Electric Strike for Cylindrical Locksets

HES 8000 Fail Safe/Fail Secure, Body Only, 12/24VDC Electric Strike

Works with cylindrical locksets and accommodates latchbolts up to 5/8" throw

Universal Electric Strike; Faceplates ordered separately

The 8000 Series Electrical Strike is a compact, high performance electric strike featuring a unique concealed design for use with cylindrical locksets. No cutting on the frame is required. Simply remove the existing strike plate, adjust the vertical alignment feature to the latchbolt centerline and install. Its strength is derived from a unique keeper pin locking design, enabling the 8000 to exceed the ratings of the frame, door and locking hardware. This field selectable fail safe/fail secure unit is easy to install and accommodates latchbolts up to 5/8" throw.

Standard Features
• No cutting on frame required
• Vertical adjustability to accommodate door sag and misalignment
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Non-handed
• Internally mounted solenoid
• Accommodates 1/2" – 5/8" [12.7mm – 15.9mm] cylindrical latchbolt (5/8" [15.9mm] with 1/8" [3.175mm] door gap)
• Strike body depth 1-1/16" [27.3mm]
• Strike body width 1-7/16" [36.5mm]
• Plug-in Connector
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood
• Aluminum

Faceplate Options
• 801 Faceplate
For use with: Cylindrical locksets in ANSI metal jambs, with latchbolts up to 5/8" [15.9mm] throw.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 801A Faceplate
For use with: Cylindrical locksets with latchbolts up to 5/8" [15.9mm] throw. Includes universal mounting tabs. Aluminum frames.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 801E Faceplate
For use with: Extended lip for ‘knock-down’ style frame installations. For use with cylindrical latchbolts up to 5/8" [15.9mm] throw.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 802 Faceplate
For use with: Cylindrical locksets with latchbolts up to 5/8" [15.9mm] throw. Includes universal mounting tabs. Aluminum frames.
ANSI/BHMA Numbers: E05031, #E09321, E09322, E09323
• 803 Faceplate
For use with: Cylindrical locksets with latchbolts up to 5/8" [15.9mm] throw. Includes universal mounting tabs. Aluminum frames.
ANSI/BHMA Numbers: E05031, E09321, E09322, E09323
• 805 Faceplate
For use with: Cylindrical locksets. Latchbolts up to 5/8" [15.9mm] throw. Four point mounting for wood installations.
ANSI/BHMA Numbers: #E05031, #E09321, #E09322, #E09323

Optional Features
• LBM Latchbolt monitor

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• RoHS compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC/VAC
• 240 mA at 12 VDC/120 mA at 24 VDC
• PoE friendly

Model: HES 8000
