HES 7000-LBM Electric Strike for Cylindrical Latchbolts and Rim Exit Devices w/ Latchbolt Monitor

HES 7000-LBM Electric Strike Body Only, Fail Safe/Fail Secure, 12/24VDC, Latchbolt Monitor

Works with cylindrical latchbolts up to 5/8" throw and rim exit devices up to a 3/4" throw

Universal Electric Strike; Faceplates ordered separately

The dual, preload solution for cylindrical latchbolts and rim exit devices. The 7000 Series Electric Strike offers two solutions to address preloaded doors. The in-frame adjustable feature allows the installer to easily adjust the electric strike opening to accommodate the horizontal position of the latchbolt after installation. The preload release function allows the electric strike to operate smoothly throughout the year under varying loads on the door caused by air conditioning pressure, changes in the weather, warped doors or doors with weather stripping that may often bind standard electric strikes. This unit accommodates cylindrical latchbolts up to 5/8" throw and rim exit latchbolts up to 3/4" throw.

Standard Features
• Stainless steel construction
• Tamper resistant
• Static strength 1,500 lbs (791 and 792 options)
• Dynamic strength 70 ft-lbs (791 and 792 options)
• Static strength 1,000 lbs (783S, 786S, and 789S options)
• Dynamic strength 50 ft-lbs (783S, 786S, and 789S options)
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Accommodates preload (up to 15 lbs: fail secure only)
• Horizontal adjustment
• Non-handed
• Internally mounted solenoid
• Strike body depth 1-11/16" [42.9mm]
• Plug-in connector
• Trim enhancer (791 and 792 options)
• Pocket adapter (786S and 789S options)
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood
• Aluminum

Faceplate Options
• 791 Faceplate
For use with: Cylindrical locksets up to 5/8" [15.9mm] throw
ANSI/BHMA Numbers: E09321, E09322, E09323
• 792 Faceplate
For use with: Cylindrical locksets up to 5/8" [15.9mm] throw
ANSI/BHMA Numbers: E09321, E09322, E09323

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed
• UL 294 listed
• RoHS compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC
• 450 mA at 12 VDC/250 mA at 24 VDC

Model: HES 7000-630-LBM
