HES 5200C-630-LBSM Grade 1 Complete Electric Strike w/ Horizontal Adjustability, Latchbolt Strike Monitor

HES 5200C-630-LBSM Grade 1 Electric Strike, Fail Safe/Fail Secure, 12/24 VDC, Latchbolt Strike Monitor, Satin Stainless Steel

Works with cylindrical locksets up to a 3/4" throw latchbolt

Complete Electric Strike; includes the 501 and 501A faceplates

The Grade 1 solution with horizontal adjustability. The 5200 Series Electric Strike features an in-frame horizontal adjustable design to simplify the installation process. This feature allows the installer to easily adjust the electric strike opening to accommodate the horizontal position of the latchbolt after the strike has been installed. This field selectable fail safe/ fail secure unit is easy to install and accommodates latchbolts up to 3/4" throw.

Standard Features
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• In-frame horizontal adjustment
• Non-handed
• Internally mounted solenoid
• Accommodates 5/8" – 3/4" [15.9mm – 19mm] latchbolt (3/4" [19mm] with 1/8" [3.2mm] door gap)
• Strike body depth 1-3/16" [30.2mm]
• Plug-in connector
• Trim enhancer included
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood

Faceplate Options
• 501 Faceplate
For use with: Cylindrical locksets in ANSI metal jambs
ANSI/BHMA Numbers: E09321, E09322, E09323
• 501A Faceplate
For use with: Cylindrical locksets or spring latch in aluminum frames. Includes universal mounting tabs.
ANSI/BHMA Numbers: E09321, E09322, E09323

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed
• UL 294 listed
• RoHS compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC/VAC
• 240 mA at 12 VDC/120 mA at 24 VDC
• PoE friendly

Model: HES 5200C-630-LBSM
