HES 5000C-630 Grade 1 Low Profile Complete Electric Strike for Cylindrical Locksets

HES 5000C Grade 1 Electric Strike, Fail Safe/Fail Secure, 12/24 VDC, Satin Stainless Steel

Works with cylindrical locksets up to a 5/8" throw latchbolt.

Complete Electric Strike; includes the 501 and 501A faceplates.

The Grade 1, low-profile solution for cylindrical locksets. The 5000 Series Electric Strike is a compact, high performance electric strike designed for low profile openings where there is limited space behind the jamb. Its strength is derived from a unique keeper pin locking design, enabling the 5000 to exceed the ratings of the frame, door and locking hardware. This field selectable fail safe/fail secure unit is easy to install and accommodates latchbolts up to 5/8" throw.

Standard Features
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Non-handed
• Internally mounted solenoid
• Accommodates 1/2" – 5/8" [12.7mm – 15.9mm] latchbolt (5/8" [15.9mm] with 1/8" [3.2mm] door gap)
• Strike body depth 1-1/16" [27.3mm]
• Plug-in connector
• Trim enhancer included
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application
• Metal
• Wood

Faceplate Options
• 501 Faceplate
For use with: Cylindrical locksets in ANSI metal jambs
ANSI/BHMA Numbers: E09321, E09322, E09323
• 501A Faceplate
For use with: Cylindrical locksets or spring latch in aluminum frames. Includes universal mounting tabs.
ANSI/BHMA Numbers: E09321, E09322, E09323

Optional Features
• LBM Latchbolt monitor

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• RoHS compliant

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC/VAC
• 240 mA at 12 VDC/120 mA at 24 VDC
• PoE friendly

Model: HES 5000C-630
