HES 4500C Low Profile Fire Rated Electric Strike

HES 4500C Grade 1 Electric Strike, Fail Safe/Fail Secure, 12/24 VDC, Low Profile, Fire Rated

Complete Electric Strike; includes faceplates for cylindrical and mortise locks.

The low profile, heavy-duty, fire rated solution. The 4500C Series Electric Strike is designed to maintain 1/2" drywall
penetration even in a 2" UL 10C fire rated frame. The 4500C features a low profile 1-3/8" depth and heavy-duty
stainless steel construction. Its strength is derived from a unique keeper pin locking design, enabling the 4500C to
exceed the ratings of the frame, door and locking hardware. The 4500C includes two faceplates designed to accommodate
either cylindrical or mortise locksets up to a 3/4" throw latchbolt.

Standard Features
• Stainless steel construction
• Tamper resistant
• Static strength 1,500 lbs
• Dynamic strength 100 ft-lbs
• Endurance 1 million cycles
• Field selectable fail safe/fail secure
• Two faceplates provided to accommodate a variety of locksets
• Non-handed
• Internally mounted solenoid
• Accommodates up to a 3/4" [19mm] latchbolt
• Strike body depth 1-3/8" [34.9mm]
• Plug-in connector
• Trim enhancer
• Full keeper shims for horizontal adjustment
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of SMART Pac® III extends the warranty to 10 years)

Frame Application - Metal

Optional Features
• LBM Latchbolt monitor
• LBSM Latchbolt strike monitor

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed
• UL 294 listed
• UL 10C fire rated, 3-hour (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• California Fire Marshal listed

Electrical (DC Continuous Duty)
• Dual voltage 12/24 VDC/VAC
• 240 mA at 12 VDC/120 mA at 24 VDC
• PoE friendly

Model: HES 4500C 630, HES 4500C 612, HES 4500C 613, HES 4500C 605, HES 4500C 606, HES 4500C 629
