HES 1006-F Grade 1 Electric Strike

HES 1006-F Grade 1 Electric Strike Body, Fail Safe 12/24VDC

The HES 1006 Series Electric Strike is the strongest and most versatile electric strike available. The dual interlocking plunger design and heavy duty stainless steel construction enables it to exceed every standard developed for electric strikes. With multiple faceplate options, the HES 1006 will fully accommodate every lock designed to work within an ANSI 4-7/8" strike plate. Tested to exceed 3,000 lbs of static strength, 350 ft-lbs of dynamic strength and factory tested to exceed 1 million cycles of operation, the HES 1006 is in a class of its own.

Specifications

Operating Voltage: 12VDC/24VDC

Amp Draw: .45 @ 12V .25 @ 24V

Keeper Size: 1 In.

Configuration: Universal

For Use With: Cylindrical Locks, Mortise Exit and Latch Locks

Holding Force: 3000 Lbs.

Frame Application: Metal or Wood

Features and benefits

Standard Features
• Stainless steel construction
• Tamper resistant
• Static strength 2,500 lbs
• Dynamic strength 350 ft-lbs (fail secure)
• Endurance 1 million cycles
• Non-handed
• Accommodates up to 1" [25.4mm] deadbolt
• Plug-in connector
• Full keeper shims for horizontal adjustment
• Trim enhancer
• Strike body depth 1-11/16" [43mm]
• SecuriCare five-year, no-fault, no questions asked warranty (Addition of HES SMART Pac® III extends the warranty to 10 years)

Faceplate Options
• J Faceplate
For use with: Cylindrical locksets up to 3/4" [19mm] throw and all locksets with center-lined bolts.
Compatible locksets: All brands of cylindrical latchbolts
ANSI/BHMA Numbers: E09321, E09322, E09323
• Z Faceplate
For use with: Unit and Mono locks
ANSI/BHMA Numbers: E09321, E09322, E09323
• E Faceplate
For use with: Corbin Russwin Security Bolt, Weiserbolt and normally extended 1" tubular deadbolts
ANSI/BHMA Numbers: E09391, E09392, E09393
• R Faceplate
For use with: Adams Rite style hookbolt up to 1" throw
ANSI/BHMA Numbers: E09391, E09392, E09393, E09332, E09333
• J-2 Faceplate
For use with: All cylindrical locks up to a 3/4" [19mm] latchbolt. Wood applications.
ANSI/BHMA Numbers: E09321, E09322, E09323
• KM-2 Faceplate
For use with: Mortise locksets up to a 3/4" [19mm] latchbolt. Wood applications.
ANSI/BHMA Numbers: E09321, E09322, E09323
• KD Faceplate
For use with: Mortise locksets up to 3/4" [19mm] throw latchbolt.
Compatible locksets: Dorma 9500, Jackson, Sargent (7700 & 8100), Schlage, Yale (8700)
ANSI/BHMA Numbers: E09321, E09322, E09323
• KM Faceplate
For use with: Mortise locksets up to 3/4" [19mm] throw latchbolt.
Compatible locksets: Accurate, Arrow, Baldwin, Best, Corbin Russwin, Falcon, Marks, PDQ, Sargent (7800, 8200 & 9200),
Yale (8800)
ANSI/BHMA Numbers: E09321, E09322, E09323
• HM Faceplate
For use with: Mortise locksets with a 1" deadbolt. Strike will not release when deadbolt is extended.
Compatible locksets: Accurate, Arrow, Baldwin, Best, Corbin Russwin, Falcon (45H, 47H, 34H & 37H), Marks, Omnia,
PDQ, Sargent (7800, 8200 & 9200), Yale (8800)
ANSI/BHMA Numbers: 09391, E09392, E09393, E09331, E09332, E09333
• HTD Faceplate
For use with: Mortise locksets with a 1" deadbolt and no deadlatch or a center positioned deadlatch. Strike will not release when deadbolt is extended.
Compatible locksets: Sargent (7700 & 8100), Schlage, Yale (8700)
ANSI/BHMA Numbers: E09391, E09392, E09393, E09331, E09332, E09333
• ND Faceplate
For use with: Mortise locksets with a deadbolt used for night latch function only.
Compatible locksets: Sargent (7700 & 8100), Schlage, Yale (8700)
ANSI/BHMA Numbers: E09391, E09392, E09393, E09331, E09332, E09333
• NM Faceplate
For use with: Mortise locksets with a deadbolt used for night latch function only.
Compatible locksets: Accurate, Arrow, Baldwin, Best, Corbin Russwin, Falcon (45H, 47H, 34H & 37H), Marks, Omnia,
PDQ, Sargent (7800, 8200 & 9200), Yale (8800)
ANSI/BHMA Numbers: E09391, E09392, E09393, E09331, E09332, E09333

Optional Features
• LBM Latchbolt monitor
• LBSM Latchbolt strike monitor
• Fail safe
• Interchangeable faceplates
• Monitor switches may not work with all faceplate options

Certifications
• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 listed
• RoHS compliant
• UL 10C fire rated, 3-hour single door (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• ANSI/SDI A250.13 windstorm resistant
• Florida Building Code approved TAS 201, 202, 203
• ANSI-ASTM E330
• Sustainability documentation
