Hager 258F Floor Stop and Holder

Hager 258F Floor Stop and Holder, Cast Brass with Rubber Bumper, 1-9/16" by 2-15/32" Base, 3" Height, 1" by 2" Keeper

Base: 1-9/16” x 2-15/32” (40 mm x 63 mm)

Height: 3” (76 mm)

Keeper: 1” x 2” (25 mm x 51 mm)

Materials: Cast brass with black rubber bumper

Fasteners: Two (2) #10 x 1” FPHWS, one (1) 1/4-20 x 3/4” FPHMS, one (1) 5/16-18 lead anchor, one (1) 1/4-20 lead anchors, and one (1) 5/16-18 x 2-1/2” threaded stud

Notes
• 1-3/8” (35 mm) max door to floor clearance
• Heavy duty - for use in high traffic areas
• For use on concrete floors
• Manual holder ideal for interior and exterior applications
• Unit functions as a stop, but can serve as a “Hold Open” when hook is manually engaged

Certification: Meets ANSI A156.16 for L01371

Model: Hager 258F US26D, 258F  US10B
