Dorma F9700 630 Fire Rated Rim Exit Device, Narrow Stile, Satin Stainless Steel Finish

Dorma F9700 630 Grade 1 Rim Exit Device, Fire Rated, Narrow Stile Pushpad, Satin Stainless Steel Finish, Non-handed

Narrow Stile
The 9000 Series narrow stile exit device with a shortened touchbar is the ultimate solution when narrow stile doors require an exit device.

The heavy-duty cast chassis design permits installation on narrow stile doors where a standard device may not fit. The smooth projection touchbar assembly minimizes catch hazards. The partial length touchpad permits field installation of options such as cylinder dogging and exit alarm.

9000 Series narrow stile exit devices are available in a wide range of models and offer a full complement of free wheeling lever trim to meet most narrow stile door applications.

Function: Exit Only – No Trim - ANSI 01

Specification
• All devices to have heavy-duty cast chassis.
• All device touchbar, rail, and cover assemblies shall be constructed of heavy gauge solid wrought materials for true architectural finishes or color coated finishes.
• The partial-length touchpad assembly accommodates field installation of options such as cylinder dogging and exit alarm.
• Non-labeled units to have hex-key dogging standard.
• All devices to have deadlocking latch bolts with 3/4" throw.
• All units shall offer a full range of free wheeling operational trim, except mortise devices.
• All units shall offer optional rigid and clutch-style trim, where applicable.
• All devices to be furnished with appropriate mounting hardware including both wood and machine screws, as well as sex nuts
where required.

9700 Features
• Door Thickness: 1-3/4" to 2-1/4"
• U.L. Listed for Labeled Fire Doors
• Extended Life Cycle Testing
• Device Handed, Not Reversible
• Latch Bolt Load Rated

Door Size
• Size BB Doors (27"–36") (touchpad 18-5/8") Default Narrow
• Size AA Doors (32-1/2"–48") (touchpad 24-5/8")

*The 9000 Series narrow stile bar lengths are designed for use on narrow stile aluminum entrance doors with a 1/2” blade stop frame. Other applications may require field cutting the bar.

Certification
• Certified/listed to ANSI/BHMA 156.3, Grade 1 for exit devices.
• U.L. and C.U.L. listed under their continuing reinspection programs and conforms to standard U.L. 10C positive pressure testing.
• Complies with NFPA 101 life safety code. Fire rated devices comply with NFPA 80 fire doors and windows.
• Devices, trim, pulls, and levers comply with the Americans for Disabilities Act, 1994, and ICC A117.1 for accessible and usable buildings and facilities.
• Contributes to U.S. Green Building Council, LEED MR Credits 2.1, 4.1, 4.2 and 5.1.
• Listed with the California Department of Forestry and Fire Protection, Office of the State Fire Marshal (wide stile devices
only).
• Hurricane-code approved to Miami-Dade County Florida and Florida State Building Code acceptance (9300, 9400, 9500, 9700).
• Meets the requirements of the California Building Code (2013) Sec. 11B-309.4 (9300BF, 9500BF, 9700BF).

Model: Dorma F9700AA 630, F9700BB 630
