Detex FV40 LD 99 Value Series Fire Rated Rim Exit Device, Less Dogging, Surface Strike

Detex FV40 LD 99 Value Series Fire Rated Wide Stile Rim Exit Device, Less Dogging, 99 Surface Strike

Technical Information
Door Types: Wood, Hollow Metal, Fiberglass or Aluminum

Door Thickness: Fits standard 1-3/4” - 2-1/4” doors

Single Door Stile: Fits 3-1/2” minimum stile doors with 99 surface strike (Std.)

Pairs of Doors Stile: Fits 4” minimum stile doors with 99 surface strike

Machine and Self-Drilling Screws (Std.)

Door Size: 36" Wide Door (3') - 48" Wide Door (4')

Finish: 628 - Satin Aluminum, 630 - Satin Stainless Steel, 711 - Satin Black

Dogging: Less Dogging

Benefits

• Priced to be the best value for durable and attractive loss prevention panic hardware
• Patented mounting plate and strike locator replaces paper templates
• Minimal door prep saves time and money
• Fast and easy installation saves time and money
• Fits almost any door in any décor
• Outside trims are easily changed or rekeyed without removing device from door
• Angled end cap deflects damage away from device

Features

• Covers a 161 door prep
• Stainless steel, 3/4" deadlocking Pullman-type latch bolt
• Non-handed
• Field sizeable
• 1/8 turn hex key dogging
• Heavy-duty ribbed aluminum rail extrusion
• High impact ABS and anodized surfaces
• Withstands over 1400 pounds of static pull force for greater security
• Modular design accepts a variety of outside trims and functions
• Standard and narrow stile pull trims available

Detex Limited Warranty
10 Year Mechanical/3 year Electrical
Limited Manufacturer’s Warranty

Model: Detex FV40 LD 628 99 36, FV40 LD 628 99 48, FV40 LD 711 99 36, FV40 LD 711 99 48
