Detex ECL-230D-PH Alarm Panic Exit Control Lock

Detex ECL-230D-PH UL-Listed Panic Hardware Exit Control Lock, with Long Bar, 38" to 48" Door Width

The ECL-230D-PH is a code compliant, battery alarmed, rugged dead bolt, panic device with steel plate and photo-luminescent sign providing managed security and a 100 decibel alarm for secondary exits.

Cylinder and bar guard sold separately.

Technical Information
• Door Types - Wood, Hollow Metal or Aluminum
• Door Thickness - Fits standard 1-3/4" - 2-1/4"
• Minimum standard door width for ECL-230D-PH is 34"
• Door Stile - Fits minimum 5-3/4" with ECL-437K Strike (Std.)
• Machine and Sheet Metal Screws (Std.)

Benefits
• Attack resistant design withstands over 2200 lbs. of outside pull force
• Proven durability and reliability at a reasonable price
• Reduces employee and customer theft
• Easy to install
• Time tested construction resists attack from the inside
• Durable steel plate with photo luminescent sign absorbs light to then “glow in the dark” when lights are dimmed
• Easy to see if the lights go out
• Straightforward operation that everyone understands

Features
• Single point, 1" throw dead bolt
• Saw resistant dead bolt
• Corrosion resistant alloy lock body
• 100 decibel alarm, powered by 9-volt battery (included)
• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders
• Resetting the alarm can only be accomplished with a control key
• Non-handed
• Locking and unlocking the dead bolt always arms and disarms the alarm

Detex Limited Warranty
10 Year Mechanical / 3 Year Electrical
Limited Manufacturers Warranty

Model: Detex ECL-230D-PH, ECL-230D-PH BLACK
