Corbin Russwin CLX3352 PZD Extra Heavy-Duty Classroom Intruder Cylindrical Lever Lock

Corbin Russwin CLX3352 PZD Extra Heavy-Duty Classroom Intruder Cylindrical Lever Lock

Function Description: Classroom Intruder
• Deadlocking latchbolt by inside lever or outside lever except when key inside or outside locks outside lever. (Lever handle
   is freewheeling in the locked position.)
• Outside lever is locked and unlocked by turning the key in the inside or outside lever.
• Inside lever always free.

Handing: Non-handed

Door Thickness: 1-3/4" (44mm) - 2" (51mm) standard.

Door Prep: ANSI/BHMA A156.115

Lock Chassis: Steel, zinc dichromated for corrosion resistance.

Backset: 2-3/4" (70mm) backset w/ 1-1/8" front (standard)
2-3/8" (60mm) backset w/ 1" wide front

Bearing Assembly: Cast and machined stainless steel

Latchbolt: Stainless Steel, 1/2" (13mm) throw. Optional: 3/4" (19mm) throw deadlocking fire latch for pair of doors.

Auxiliary Latchbolt: Deadlocking latchbolt prevents manipulation when door is closed.

Front: Wrought brass or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm).
Accommodates flat front doors and doors beveled 1/8" (3mm) in 2" (51mm).

Strike: Wrought brass or stainless steel ANSI curved lip standard, 4-7/8" (124mm) x
1-1/4" (32mm) x 1-1/4" (32mm) lip to center.

Levers: Secured with 6 lobe security set screw standard

Roses: Brass

Cylinder: Brass, 6-pin L4 keyway,

Keying Features Available:
Master keying, Construction master keying, Visual key control, Concealed key control,
Interchangeable core (LFIC or SFIC), Security, Security LFIC, Access 3® LFIC, Pyramid, Pyramid LFIC

Keys: Two nickel silver standard.

Warranty: Ten-year limited.

Certification/Compliance:
ANSI/BHMA
Certified ANSI/BHMA A156.2 (2017) Series 4000 — Grade 1
Certified ANSI/BHMA A156.41

UL/cUL
UL/cUL listed to US and Canadian safety standards for 3 hour doors up to 4' x 10' (double doors require 41- option)

NFPA 80
Conforms for life safety and property protection, Standard for Fire Doors and Other Opening Protectives

Positive Pressure
Meets ANSI/UL 10C, Positive Pressure Fire Test of Door Assemblies

ADA
All levers conform to ADA clear opening width requirements of ANSI A117.1

California State Reference Code (Formerly Title 19, California State Fire Marshal Standard)
All levers with returns comply; levers return to within 1/2" (13mm) of door face

Windstorm/Hurricane
All individual components of a total door opening are required to comply with each code.

Model: Corbin Russwin CLX3352 PZD 626, CLX3352 PZD 605, CLX3352 PZD 606, CLX3352 PZD 612, CLX3352 PZD 613, CLX3352 PZD 625, CLX3352 PZD 626 M08, CLX3352 PZD 605 M08, CLX3352 PZD 606 M08, CLX3352 PZD 612 M08, CLX3352 PZD 613 M08, CLX3352 PZD 625 M08, CLX3352 PZD 626 CL6, CLX3352 PZD 605 CL6, CLX3352 PZD 606 CL6, CLX3352 PZD 612 CL6, CLX3352 PZD 613 CL6, CLX3352 PZD 625 CL6, CLX3352 PZD 626 LC, CLX3352 PZD 605 LC, CLX3352 PZD 606 LC, CLX3352 PZD 612 LC, CLX3352 PZD 613 LC, CLX3352 PZD 625 LC
