Corbin Russwin CLX3332 NZD Extra Heavy-Duty Institutional or Utility Cylindrical Lever Lock

Corbin Russwin CLX3332 NZD Grade 1 Institutional/Utility Cylindrical Lock, Newport Lever, Non-handed

Function Description: Institutional or Utility - ANSI F87
• Deadlocking latchbolt by key either side. (Lever handles are freewheeling in locked position.)
• Should be used only in office or room with multiple entries.

Handing: Non-handed

Door Thickness: 1-3/4" (44mm) - 2" (51mm) standard.

Door Prep: ANSI/BHMA A156.115

Lock Chassis: Steel, zinc dichromated for corrosion resistance.

Backset: 2-3/4" (70mm) backset w/ 1-1/8" front (standard)

Bearing Assembly: Cast and machined stainless steel

Latchbolt: Stainless Steel, 1/2" (13mm) throw. Optional: 3/4" (19mm) throw deadlocking fire latch for pair of doors.

Auxiliary Latchbolt: Deadlocking latchbolt prevents manipulation when door is closed.

Front: Wrought brass or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm).
Accommodates flat front doors and doors beveled 1/8" (3mm) in 2" (51mm).

Strike: Wrought brass or stainless steel ANSI curved lip standard, 4-7/8" (124mm) x
1-1/4" (32mm) x 1-1/4" (32mm) lip to center.

Levers: Secured with 6 lobe security set screw standard

Roses: Brass

Cylinder: Brass, 6-pin L4 keyway,

Keying Features Available:
Master keying, Construction master keying, Visual key control, Concealed key control,
Interchangeable core (LFIC or SFIC), Security, Security LFIC, Access 3® LFIC, Pyramid, Pyramid LFIC

Keys: Two nickel silver standard.

Warranty: Ten-year limited.

Certification/Compliance:
ANSI/BHMA
Certified ANSI/BHMA A156.2 (2017) Series 4000 — Grade 1
Certified ANSI/BHMA A156.41

UL/cUL
UL/cUL listed to US and Canadian safety standards for 3 hour doors up to 4' x 10' (double doors require 41- option)

NFPA 80
Conforms for life safety and property protection, Standard for Fire Doors and Other Opening Protectives

Positive Pressure
Meets ANSI/UL 10C, Positive Pressure Fire Test of Door Assemblies

ADA
All levers conform to ADA clear opening width requirements of ANSI A117.1

California State Reference Code (Formerly Title 19, California State Fire Marshal Standard)
All levers with returns comply; levers return to within 1/2" (13mm) of door face

Windstorm/Hurricane
All individual components of a total door opening are required to comply with each code.

Model: Corbin Russwin CLX3332 NZD 626, CLX3332 NZD 605, CLX3332 NZD 606, CLX3332 NZD 612, CLX3332 NZD 613, CLX3332 NZD 625, CLX3332 NZD 626 M08, CLX3332 NZD 605 M08, CLX3332 NZD 606 M08, CLX3332 NZD 612 M08, CLX3332 NZD 613 M08, CLX3332 NZD 625 M08, CLX3332 NZD 626 CL6, CLX3332 NZD 605 CL6, CLX3332 NZD 606 CL6, CLX3332 NZD 612 CL6, CLX3332 NZD 613 CL6, CLX3332 NZD 625 CL6, CLX3332 NZD 626 LC, CLX3332 NZD 605 LC, CLX3332 NZD 606 LC, CLX3332 NZD 612 LC, CLX3332 NZD 613 LC, CLX3332 NZD 625 LC
