Alarm Lock PL3000IC Trilogy Cylindrical Prox Only Lock, SFIC Prep, Less Core

Alarm Lock PL3000IC Prox Reader Cylindrical Door Lock, 300 Users, 1600 Event Audit Trail, Straight Lever, SFIC Prep, Less Core

Ultra vandal-deterrence; No keys and no PINs to record or administer

Operation: Authorized Prox credential (HID card, keyfob or prox tag) allows lever to retract latch. Inside lever is always in passage mode and permits instant egress.

• Field-proven, rugged keypad-less lock with ultra-vandal-proof prox reader built in. Standalone lock – no wiring; long-life battery operation. (Key override with IC core option.)
• Users are individually programmed to gain access only with HID prox cards, prox keyfobs or prox tags, for the highest level of vandal-resistance and dependability available.
• 2000 individual users gain entry access using new or legacy HID Prox ID cards, prox keyfobs or prox tags. No keys or PIN codes to record or administer. 100% Prox, keypad-less security for fastest entrant processing and the highest level of dependable, vandal-deterrent standalone access control locking.
• Weather proof performance, water-sealed for use inside and out, with operational temperature range of +151°F to -31°F (+66°C to -35°C)
• Program/add users with Trilogy® DL-WINDOWS PC Programming, or by presenting valid cards to prox reader on the lock face, while in programming mode. (Note: Programming mode is activated by using one of the nine preprogrammed cards furnished with the lock.)
• Scheduled Events: Real time clock enables up to 500 scheduled events and holiday schedules. Program to lock/unlock; disable/enable users; 4 built-in time schedules
• Audit Trail with Time/Date Stamp Log: Up to 40,000 event audit trail with printed time/date-stamped log of all electronic activity can be reported from the lock including user entry, unlock/lock events, program mode changes,
user entry, keypad lockout, remote release events, unauthorized code attempts, etc., by using the AL-IR1 (infrared printer), the AL-DTM (data transfer module) or PCI2 (PC interface). Program data transferred to lock via AL-PCII
(PC interface) or (AL-DTMII data transfer module).
• “First-Manager-in” controls three (3) different features: Passage mode, group of users and relay options
• Programmable Form C Relay functions for schedules of manual control of CCTV, lighting, ambush function, alarm system, etc.

Operating Temperature: Weatherproof lock with operating range from -31 degrees below to 151degrees F.

Lock/Built-in Reader: Weatherproof and moisture sealed circuitry. Proximity antenna is housed within ultra high strength, impact resistant Lexan®.

Programming: Locking modes, event schedules, group or individual users, master and management codes, passage and emergency or service access, lockout and remote override capability and allowable entry time (3, 10 or 15 seconds), etc. are programmable via Alarm Lock DL – Windows PC Software the AL-DTM (data transfer module).
Note: Lock includes 9 preprogrammed Prox Cards for initialization /programming.)

Door Thickness: 1 5/8" to 1 7/8."

Backset: 2 3/4" Standard. 2 3/8" backset also available

Standard Key Override Cylinder: Solid brass 6 pin tumbler cylinder keyed 5, SCI keyway, furnished in all K.O. models.

Cylinder Type: SFIC Prep Less Core

Audit Trail: Lock’s activity log can be extracted by using the AL-DTMII (data transfer module**), the AL-PCI (PC interface**) and/or can be on-site printer using the AL-IR1 (hand-held infrared printer). (**Note: Requires intermediary PC running DL-WINDOWS software.)

Strike: 1 1/8” x 2 3/4” T strike standard. With screws for wood or metal jambs. 1 1/4” x 4 7/8”. ASA strike also included.

Finishes: US3 polished brass, US26D satin chrome, 10B Duronodic

Power: 5AA alkaline batteries, furnished. Audible low battery alert, visual and audible entry indicators; 60,000 cycles, typical.

Programming: Locking modes, event schedules, group, individual, master, management, passage, emergency service codes. Lockout, remote override capability and allowable entry time (3, 10 or 15 seconds), are programmable through the keypad, AL-DTMIII or Alarm Lock's DL-Windows PC Software.

Door Prep: Standard ANSI A115 Series Prep modified by adding additional through-bolt holes

Compliances: Grade I heavy duty cylindrical lockset. UL listed to the 1OC Positive Pressure Specification. Latchbolt is UL listed and 3-hour fire rated. FCC certified. ADA compliant levers.

Model: Alarm Lock PL3000IC US26D
