Adams Rite 8600C Narrow Stile Concealed Vertical Rod Exit Device w/ Cylinder Dogging

Adams Rite 8600C Narrow Stile Concealed Vertical Rod Exit Device, For Aluminum Applications, Cylinder Dogging, 36" Device

The 8600 Series Narrow Stile Concealed Vertical Rod Exit Device is designed for narrow stile aluminum applications that require a life-safety exit device with concealed vertical rods for two-point locking. Designed for use in applications with single doors or pairs of doors.

Cylinder Dogging
Suitable for all non-fire rated Adams Rite exit devices that require management control of exit device dogging. Any standard 15/16” [23.8 mm] to 1-1/8” [28.6mm] length, 1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder can be used in a pushbar prepared at factory with Cylinder Dogging kit. Cannot be ordered with any other exit device options.

Features
Materials: Push bar made of extruded aluminum, available in a variety of finishes.

Handing: Device is non-handed.

Push bar Length
Standard sizes: dimensioned for 36" [914.4 mm] openings. Standard width bars can be field cut to the next smallest opening width.

Bar Height: Standard model adjusts from 30" [762 mm] to 44" [1117.6 mm].

Fasteners: Standard machine screws.

Projection: 2-15/16" [74.6 mm] when fully projected, 1-15/16" [49.2mm] when dogged.

Door Height: Standard configuration suitable for doors up to 66" [1,676.4 mm] above the selected bar height.

Door Thickness: Suits 1-3/4" [44.5 mm] standard, up to 2-1/4" [57.2 mm].

Stile Width: Minimum 2" [50.8 mm] stile. Fits narrow, medium, and wide stile aluminum doors.

Stile Wall: Doors with stile walls other than 1/8" [3.2 mm] require modification.

Bolts and Strikes: The patented top latching mechanism utilizes a rotating top bolt which deadlatches around the header strike, interlocking the door to the frame. Supplied with standard header strike. Adjustable protected steel rods. The hexagonal, hardened steel bottom bolt is shielded in a cast housing for strength and stability.

Certifications
UL 305 Panic hardware
ANSI/BHMA A156.3, Grade 1

Model: Adams Rite 8611C-36, 8622C-36
