Adams Rite 8400LR Narrow Stile Mortise Exit Device w/ Electric Latch Retraction

Adams Rite 8400LR Life Safety Narrow Stile Mortise Exit Device, For Aluminum Applications, 1-1/8" Backset, Electric Latch Retraction

The 8400 Series Narrow Stile Mortise Exit Device is designed for narrow stile aluminum applications that require a life-safety exit device with mortise locking solution. Designed for use in single door applications.

Electric Latch Retraction (solenoid)
The LR option for all other exit devices (non-rim exit devices) use a solenoid mounted under the pushbar for instantaneous unlocking and locking of the exit device from a remote location or access control device. Because electrical operation of device is fail-secure, this option can be used on fire-rated as well as life-safety applications. In the event of a power failure, device automatically relocks.

LR Option
• Solenoids are rated for both intermittent and continuous operation
• 16 Amps inrush/ 0.5 Amps hold

Features
Materials: Push bar made of extruded aluminum, clad or anodized in a variety of finishes.

Handing: Specify handing.

Push bar Length
Standard sizes: dimensioned for 30" [762.0 mm], 36" [914.4mm], 42" [1,066.8 mm] openings. Standard width bars can be field cut to the next smallest opening width.

Face Shape: 0 - Flat, bevel, radius

Backset: 1-1/8" [28.6 mm]

Door Thickness: Suits 1-3/4" [44.5 mm] standard.

Stile Width: Minimum 2" [50.8 mm] stile. Fits narrow, medium, and wide stile aluminum doors.

Projection: 2-5/8" [66.7 mm] when fully projected, 1-5/8" [41.3 mm] when dogged.

Dogging: Standard dogging with hex key.

Fasteners: Standard machine screws.

Bolts and Strikes: Mortise deadlatch with bolt measuring 5/8" x 1" x 5/8" [15.9 mm x 25.4 mm x 15.9 mm] throw. Solid brass bolt.
• Standard strike of stainless steel included.

Certifications
UL 305 Panic Hardware
ANSI/BHMA A156.3, Grade 1

Model: Adams Rite 8410LR-38036, 8410LR-38030, 8410LR-38042, 8410LR-37036, 8410LR-37030, 8420LR-37042, 8420LR-38036, 8420LR-38030, 8420LR-38042, 8420LR-37036, 8420LR-37030, 8420LR-37042
