Adams Rite 7410M Ultraline Electric Strike w/ Monitoring Switches, 1-7/16" x 7-15/16" Flat Faceplate for Aluminum, Hollow Metal/Wood Jamb

In Stock
$280.37
Price: $472.00
Instant Savings $191.63

FREE SHIPPING

SKU: 7410M628
Series: 7400
Face Plate Length: 1-7/16" x 7-15/16"
Switch Type: Monitored
Lockset type: For Cylindrical or Deadlatch Locks
Choose Options:
Hurry! Only left

Adams Rite 7410M Electric Strike, For Aluminum, Hollow Metal or Wood Applications, 1-7/16" x 7-15/16" Flat Faceplate with Radius Corners, Field Selectable (Fail Safe/Fail Secure), Monitored

Designed for use with Adams Rite deadlatches or cylindrical locksets with 1/2" [12.7 mm] to 5/8" [15.9 mm] latchbolt projection.

Function
This non-handed strike features an ultra-compact design and adjustable stainless steel keepers with over 1,500 lbs [680.4 kg] of holding force in fail secure mode. The strike releases electrically with up to 25 lbs of door preload. Single solenoid operates on 12/16/24 VDC power. Remote electrical control of narrow stile aluminum doors equipped with an Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical lockset with 1/2" [12.7 mm] to 5/8" [15.9 mm] latchbolt projection. Electrical actuation unlocks the keeper, releasing the latchbolt so the door may be opened without operating the latch itself.

Monitoring switches to indicate when the latchbolt is engaged in the strike jaws and a locked/unlocked solenoid status.

Features:

Faceplate: 1-7/16" x 7-15/16" [36.5 mm x 201.6 mm] Flat with radius corners

Switch TypeMonitored

Latchbolt Projection: 1/2" to 5/8” [12.7 mm to 15.9 mm]

Preload: 7400 Series Electric Strikes open electrically under 25 lbs [11.3 kg] of preload. Preload is pressure exerted on doors by air conditioning systems, warping or misaligned hardware which can disable common electric strikes. Using jaw inserts of various sizes, the Ultraline 7400 Series electric strikes are adjustable to compensate for door and frame related preload and security problems.

Electrical VoltageField selectable to match power source of 12/24 VDC. VA7400-16 VDC voltage adapter required when using 16 VDC power, available separately. Equipped with a quick connect plug-in type connector.

Current Draw
44A at 12 VDC
.46A at 16 VDC - Requires 16 DC adapter (P/N VA7400-16VDC)
.23A at 24 VDC

Fail Safe | Fail Secure: Field selectable fail safe/fail secure

Case: 1-13/32" x 3-3/8" x 1-1/16" deep [35.7 mm x 85.7 mm x 27 mm deep]

Strike Opening: 5/8" adjustable x 1-7/16" x 1/2" deep [15.9 mm adjustable x 36.5 mm x 12.7 mm deep]. Bolt retaining keeper is stainless steel. Strike accepts bolt of Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical locksets.

Strike Lip: Basic 7400 strike has lip of proper length for 1-3/4" [44.5 mm] thick door that closes flush with jamb edge. Where door thickness or jamb shape differs from this standard relationship, lip extension kits are available. Lip extension kits not available on 7401, 7431

Standard Package: Individually boxed with mounting screws, mounting tabs, adhesive shims to accommodate jamb or stile extrusion thickness greater or less than nominal 1/8" [3.2 mm], an adjustable keeper shim pack and two plug-in voltage adapters for 12/24 VDC.

Certifications
UL 1034 Burglary-Resistant Listed and Suitable for Outdoor Use
UL 294
ULC-S319
ANSI/BHMA A156.18
ANSI/BHMA A156.31 Electric Strikes and Frame Mounted Actuators, Grade 1

Model: Adams Rite 7410M628, 7410M335, 7410M313, 7410M630
